AsRock B650M PRO RS AM5 retail
AM5, AMD B650, mATXPrice in EUR including VAT, free shipping
Delivered Mon, 6.1.
More than 10 items in stock
More than 10 items in stock
Product details
The Asrock B650M Pro is equipped with the B650 chipset for AMD's Ryzen processors of the 7000 series and offers numerous features for enthusiasts and gamers. Since the Ryzen 7000 series processors require
a socket due to the support of PCIe 5.0 and the extended power supply, the socket AM5 (LGA 1718) is used on the 600 series mainboards. Despite the increased number of pins, the actual size of the socket remains identical to older sockets, so that most CPU coolers for socket AM4 can also be mounted on the mainboard.
| Processor family | Ryzen 3 7th Gen, Ryzen 5 7th Gen, Ryzen 7 7th Gen, Ryzen 9 7th Gen |
| Memory type | DDR5 RAM |
| Internal connection options | 24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 PCIe (1x), S-ATA III (4x) |
| Peripheral connections | USB 2.0 Type-A (8x), USB 3.2 Gen 2 (1x), USB Type-C (2x) |
| Item number | 35511148 |
| Manufacturer | |
| Category | |
| Manufacturer no. | 90-MXBLP0-A0UAYZ |
| Release date | 17.5.2023 |
| Form factor | Micro ATX (mATX) |
| Processor socket | AM5 |
| Chipset | AMD B650 |
| Mainboard features | Front panel audio connector, Thunderbolt header |
| Operating system compatibility | Windows, Windows 10 |
| Peripheral connections | USB 2.0 Type-A (8x), USB 3.2 Gen 2 (1x), USB Type-C (2x) |
| BIOS type | UEFI AMI |
| Processor family | Ryzen 3 7th Gen, Ryzen 5 7th Gen, Ryzen 7 7th Gen, Ryzen 9 7th Gen |
| Memory form factor | DIMM |
| Number of memory modules (RAM) | 4 x |
| Max. memory (RAM) | 128 GB |
| Memory chip | DDR5 SDRAM |
| Max. RAM OC | 6000 MHz |
| Supported memory speed | 6000 MHz |
| Memory type | DDR5 RAM |
| RAM buffer | Unbuffered |
| Video connections | DisplayPort (1x), HDMI (1x) |
| Video connection version | HDMI 1.4 |
| Multi-GPU technology | AMD CrossFire |
| Network connections | RJ45 (1x) |
| Ethernet controller brand | Realtek |
| Ethernet controller | Dragon RTL8125BG |
| Max. port speed | 2.50 Gbit/s |
| Chip | Realtek ALC897 |
| Audio channel | 7.1 Channel |
| Audio Connections | Headphone output (1x), Microphone |
| Internal connection options | 24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 PCIe (1x), S-ATA III (4x) |
| Expansion slot | PCI Express x16 (1x) |
| Number of fan connector | 5 |
| Power connectors | 8-pin PCI-E |
| Scope of delivery | 2 x Serial ATA cable |
| Length | 244 mm |
| Width | 244 mm |
| Height | 65 mm |
| Weight | 1242 g |
| Length | 28 cm |
| Width | 26 cm |
| Height | 6 cm |
| Weight | 1.24 kg |
Specifications may include unverified machine translations.
